Triyosys MPT (Motorized Pan Tilt) units carry cameras, thermal imagers, radars, laser range finders and other payloads on land, naval and fixed-site platforms. All models provide continuous 360° pan rotation and 0.02° positioning accuracy (MD-BLG01: 0.05°). The table below summarizes the key values of each series so you can quickly shortlist the right unit.
MPT Series Technical Comparison
| Model | Payload (kg) | Max pan speed (°/s) | Max tilt speed (°/s) | Tilt range | Weight (kg) | Supply (V DC) |
|---|---|---|---|---|---|---|
| MPT-W66 | 6 | 60 | 24 | 135° (+90/−45) | 3.6 | 18–32 |
| MPT-D-1 | 8 | 90 | 60 | 120° (+90/−30) | 4.3 | 20–32 |
| MPT-D-2 | 30 | 60 | 60 | 120° | 5.6 | 20–32 |
| MPT-I-1 | 8 | 90 | 60 | 180° | 4.5 | 20–32 |
| MPT-I-2 | 30 | 60 | 60 | 180° | 5.5 | 20–32 |
| MPT-T-1 | 30 | 60 | 60 | 180° | 12.5 | 20–32 |
| MPT-T-2 | 65 | 60 | 60 | 180° | 15.8 | 38–56 |
| MPT-L-2 | 6 | 60 | 60 | 180° | 6.3 | 20–32 |
| MPT-L-3 | 75 | 90 | 60 | 180° | 14 | 18–32 |
| MPT-HS | 30 | 180 | 60 | 180° | 9 | 20–32 |
| MPT-EO-2 | 30 | 90 | 60 | 180° | 14.2 | 18–32 |
| MPT-EO-3 | 75 | 90 | 60 | 180° | 15.8 | 18–32 |
| MPT-U Stabilized | 45 | 120 | 60 | 180° | – | 20–32 |
| MPT-U-2 | 45 | 60 | 60 | 90° (±45) | 20.6 | 18–32 |
| MPT-DUAL-2 | 90 | 60 | 60 | 180° | 60 | 20–32 |
| MPT-HD-1 | 120 | 36 | 24 | 180° | 45 | 44–52 |
| MD-BLG01 | 100 | 36 | manual * | ±10° * | 45 | 18–32 |
* MD-BLG01 has manual tilt adjustment (±10°). MPT-U Stabilized offers ±1 mrad gyro stabilization accuracy. Values are taken from the product data sheets on our website; see each product page for full specifications and options.
Which Series Should You Choose?
- Light payloads (up to 8 kg): MPT-W66, MPT-D-1, MPT-I-1 and MPT-L-2 offer compact and light solutions.
- Medium payloads (30–45 kg): MPT-D-2, MPT-I-2, MPT-T-1, MPT-EO-2 and MPT-U series; choose MPT-HS when you need 180°/s pan speed for fast target tracking.
- Heavy payloads (65 kg and above): MPT-T-2, MPT-L-3, MPT-EO-3, MPT-DUAL-2, MD-BLG01 and MPT-HD-1 (120 kg).
- Moving platforms: for vehicles and vessels, the gyro-stabilized MPT-U keeps the line of sight steady; see gyro stabilization.
For a detailed selection guide read How to Choose a Pan Tilt Unit, browse all motorized pan and tilt units, or contact us for a recommendation for your payload.
